Hydraulic Magnetic Circuit Breaker/ Switch
Quantity:
B3S 3P 1A-125A
B3S series circuit breaker for equipment are suitable for overload and short circuit protection in electrical systems with rated current 1A to 125A, AC 50/60 Hz, rated voltage AC 240V and below, and also for infrequent connection and disconnection.
Current rating: 1A ~ 125A
Rated insulation voltage Ui (V): 500V
Rated impulse withstand voltage Uimp（V）：4kV
Electrical lifecycle: 6000
Mechanical lifecycle: 10000
Working temperature：-40℃~ +85℃
Standards：GB/T 14048.2 /IEC 60947-2, UL489
