Hydraulic Magnetic Circuit Breaker

Quantity:
Contact Now
Add To Cart
B3C 2P 1A-30A UL489
The circuit breaker is used in AC50Hz/60Hz,rated voltage AC240V, 250V and 400V equipment network circuit. It is mainly used for a variety of equipment and lines to provide accurate and reliable short circuit and overload protection.
Maximum voltage: 400VAC 50/60 Hz
Current Ratings: 1A to 30A
Operating Temperature: -40℃ to +85℃
Number of poles: 1 pole, 2 poles
Agency Certifications: UL489，IEC/EN60934，GB17701
