Hydraulic Magnetic Circuit Breaker

Quantity:
Contact Now
Add To Cart
B2R 1P 1A-63A UL1077, UL489
B2 Series circuit breaker is used in AC50Hz/60Hz, rated voltage DC80V or AC250V equipment network circuit.It is mainly used for a variety of equipment and lines to provide accurate and reliable short circuit and overload protection.
Maximum voltage: 277VAC 50/60 Hz, 80VDC
Current Ratings: 1A to 63A
Auxiliary switch: SPDT,5A 250VAC, 1.0A 80VDC
Operating environment: -40℃ to +85℃
Complying with: IEC 60934, UL1077, GB17701，UL489 and EN 60947-2
