Hydraulic Magnetic Circuit Breaker/Switch
Quantity:
B2R 2P 1A-63A UL1077, UL489, TUV
Thecircuit breaker is used in AC50Hz/60Hz,rated voltage DC80V or AC250V equipment network circuit. It is mainly used for a variety of equipment and lines to provide accurate and reliable short circuit and overload protection.
Maximum voltage: 277VAC 50/60 Hz, 80VDC
Current Ratings: 1A to 63A
Auxiliary switch: SPDT,5A 250VAC, 1.0A 80VDC
Operating environment: -40℃ to +85℃
Number of poles: 1 pole, 2poles, 3 poles, 4 poles
Complying with: IEC 60934, UL1077, GB17701，UL489 and EN 60947-2
