Overload Protector/ Switch/Breaker
Quantity:
BC5-25 3A, 5A, 7A, 10A, 12A, 16A, 20A, 25A
BC5 Series Supplementary Protector can be used in electric system which rated current from 3A to 50A, 50/60Hz, voltage AC 250V and DC65V to protect the overload and short of circuit. It is largely used in industrial automation equipment, telecommunication equipment, communication power , UPS and so on.
Maximum voltage：125/250VAC 50/60 Hz，32/65VDC
Current Ratings：3A-25A
Insulation resistance：Minimum of 100 Megohms at 500VDC
Dielectric strength：1500V, 50/60Hz for one minute between all terminals
Operating Temperature Range：-10℃—+60℃
Standard：IEC 60934, UL1077, GB17701, CSA235
